SOP510 weighing transmitter for aluminum profile shell
Brand SOP
Product origin JiangXi
Delivery time 3days
Supply capacity 300pcs/day
The SOP510 transmitter adopts an aluminum profile shell, with original imported high-performance devices used internally to precisely amplify the sensor output signal. Internally, it undergoes voltage stabilization, constant current bridge supply, voltage current conversion, impedance adaptation, linear compensation, humidity compensation, etc. Convert mechanics and quantities into standard current and voltage signals for output, which can switch between 0 ± 5V/0 ± 10V/4-20mA/0-20mA. It can directly interface with automatic control equipment such as PLC, microcontroller, upper computer terminal, or be connected to a computer network. Equipped with standard signal external zero and external gain adjustment functions, input over protection, output short circuit protection, and other characteristics.
Product description
The SOP510 transmitter adopts an aluminum profile shell, with original imported high-performance devices used internally to precisely amplify the sensor output signal. Internally, it undergoes voltage stabilization, constant current bridge supply, voltage current conversion, impedance adaptation, linear compensation, humidity compensation, etc. Convert mechanics and quantities into standard current and voltage signals for output, which can switch between 0 ± 5V/0 ± 10V/4-20mA/0-20mA. It can directly interface with automatic control equipment such as PLC, microcontroller, upper computer terminal, or be connected to a computer network. Equipped with standard signal external zero and external gain adjustment functions, input over protection, output short circuit protection, and other characteristics.
Product features
1.Aluminum profile shell
2.Internally using original imported high-performance components
3.Equipped with standard signal external zero and external gain adjustment functions, input over protection, output short circuit protection, and other characteristics
Connection method
| Parameter | Technical parameter |
| Supply voltage | 15-30VDC |
| Sampling frequency | ≥100KHz |
| Input signal | 0.5-4mV/V |
| Comprehensive precision | 0.05% |
| Working temperature | -30℃-80℃ |
| Output signal | 0±5V、0±10V、0-20mA、4-20mA |
